USA-96JC-E · Tracked Jaw Crusher with Two-Deck Screen
Built like equipment used to be.
Simple by Design.
Built to Work.
A 60–150 tph tracked jaw crusher with a two-deck screen built in — one machine, one operator, up to three sized products off the belts — built around conventional diesel-hydraulic systems a qualified technician can actually work on.
- ~ 35" × 20" jaw
- 60–150 tph
- Two-deck screen
- Magnet included
- 41,900 lb
- Steel tracks
Supported machine, built to order. 1-year parts warranty and first-year field-service coverage included.
Prices are for the standard supported machine, before options, delivery and applicable tax. Delivery quoted to your site.
Right-size it
Crush and screen in one pass — or run two machines?
The 96JC-E is the top of the tracked jaw line: the biggest jaw, the highest output, and a screen box on board so the product comes off sized. Here's how it sits next to the 704 and the 805, so you buy the machine your material needs and not the one that impresses at the yard.
| USA-704JC | USA-805JC | USA-96JC-E | |
|---|---|---|---|
| Jaw opening | 26.8" × 16.9" (680 × 430 mm) | 31.5" × 19.7" (800 × 500 mm) | 35.4" × 19.7" (900 × 500 mm) |
| Max feed | 13.8" (350 mm) | 16.7" (425 mm) | 16.7" (425 mm) |
| Rated production | 30–80 t/h | 50–100 t/h | 60–150 t/h |
| Screening | None built in — pair with a screener | Grizzly pre-screen with side conveyor | Two-deck screen — up to three sized products |
| Operating weight | 29,760 lb (13,500 kg) | 48,502 lb (22,000 kg) | 41,888 lb (19,000 kg) |
| Transport (L × W) | 19'6" × 7'3" (5,950 × 2,200 mm) | 29'2" × 8'2" (8,900 × 2,500 mm) | 38'1" × 7'3" (11,600 × 2,200 mm) |
| Price | $172,400 | $264,900 | $322,900 |
| Availability | Stocked in the U.S. | Factory order | Factory order |
Rated production depends on material, feed size, discharge setting and screen media. If you sell more than one product size, the 96JC-E replaces a crusher-plus-screener train; if you sell one product and want stock now, look at the 704.
See it work
Watch the 96JC-E work in the video above. Want to discuss material like yours or see a machine in person? Ask on the quote form and we'll tell you what's possible.
The idea behind the machine
Built like equipment used to be.
Heavy equipment keeps getting more complicated. More sensors, more controllers, more proprietary software between the operator and the machine — and more ways for a machine to stop that nobody on your site can diagnose.
UPSEN takes a different approach. The USA-96JC-E is designed around conventional diesel-hydraulic systems and components a qualified heavy-equipment technician will recognize: a diesel engine, hydraulic drive, a vibrating pre-screen feeder, a jaw, a two-deck screen box, belts, steel tracks. Technology stays where it makes the machine better to run — the available remote control, for one. It doesn't get added because it can be.
Some manufacturers go the other way and build more integration into their machines. That's a legitimate choice. So is this one. Which philosophy fits you comes down to one question: who's going to work on it?
Mechanical where it matters
Diesel-hydraulic drive. Conventional systems. Nothing proprietary standing between you and the machine.
Understandable
Designed so qualified heavy-equipment technicians can understand it, diagnose it and service it — your mechanic, or an independent technician we coordinate.
Built for the job
It crushes, it screens, it tracks. Everything you need to do the job. Less of what you don't.
This isn't nostalgia. It's a decision about what a crusher is for.
Why the 96JC-E
What you're actually buying.
Six things the USA-96JC-E does that matter on a job, in the order producers ask about them.
Crush and screen in one pass
Concrete, asphalt or rock goes in the hopper; up to three sized products come off the belts. One machine to move, one to fuel, one operator to pay — and no second machine to buy, haul and set up.
Production-class output
Rated 60–150 tph through a 35.4" × 19.7" (900 × 500 mm) jaw that takes a 16.7" (425 mm) feed. Slabs, footings and shot rock go in with less breaking-down first, and the pile keeps up with a loader.
Diesel-hydraulic simplicity
A 207 HP (154 kW) diesel and hydraulic drive. Conventional systems a technician can trace with a schematic and a gauge, not a laptop and a login.
Practical serviceability
Manganese-steel jaw plates — the same wear metallurgy the rest of the industry runs. Common wear parts and screen media, stocked in the U.S. A full English operator's manual written to be used, not filed.
Pre-screen and magnet, standard
A grizzly pre-screen pulls fines out before the jaw so you crush rock, not dirt. A belt magnet over the discharge pulls rebar and tramp steel out of your product. Both come with the machine — not as options.
Supported from day one
Built to order for the U.S. market. A 1-year parts warranty and first-year field-service coverage included. Wear and service parts on the shelf here. Financing through our lending partners. Delivery quoted to your site.
Pricing
What it costs, and what comes with it.
The USA-96JC-E is sold as a supported machine. The price includes the coverage a crusher should come with — not just the iron.
$322,900
Built to order and delivered to your site. Options and delivery quoted separately.
Included with every USA-96JC-E
- 1-year manufacturer parts warranty
- 12 months of field-service coverage, coordinated by UPSEN USA
- Factory troubleshooting relayed through UPSEN USA — a direct line to the people who built it
- Wear and service parts stocked in the U.S., shipped same or next business day
- Full English operator's and parts manual
- Delivery quoted to your destination — no flat-rate guesswork
Estimated monthly payment
— /mo · 60 months
Estimate — 60 months at ~10.7% APR. Final terms set by the lender on approved credit.
Based on the listed machine price.
Financing
Available through our lending partners. Getting pre-approved before we talk keeps the whole process moving. Apply for financing →
Configure it
Dust suppression, service and wear kits, screen media cut to the products you sell — priced on your quote. Tell us what you're crushing and what you sell, and we'll tell you what you actually need.
Price is for the standard supported machine, before options, delivery and applicable tax.
Support & warranty
What support looks like.
UPSEN USA backs every machine it sells with a direct line to the factory, wear parts stocked in the U.S., and field service coordinated by our own support team. Here's how it works when you need it.
You call UPSEN USA
Call, text or email our support team with photos or video. You reach people who know the machine — and who talk to the factory directly.
We work it with the factory
UPSEN USA takes the issue straight to the manufacturer and comes back with a clear next step: what to check, what to adjust, what to replace.
Parts ship fast
Wear and service parts ship from our U.S. stock same or next business day — most customers have them in hand within 2–3 days. Factory-sourced components are air-freighted.
Field service, coordinated by us
If the fix needs hands on the machine, UPSEN USA dispatches an insured, independent heavy-equipment technician and manages the job start to finish. In your first 12 months, covered work draws on the field-service coverage included with the machine.
Full coverage terms come with your proposal.
One accountable company. Parts in stock in the U.S. A direct line to the factory. That's the structure — and it's what you get.
Options
Configure the machine.
Add what your material needs and skip what it doesn't. Each option is priced on your quote, with the machine.
Water dust suppression
Priced on your quote
Spray system for dust control at the crusher, screen and discharge. Water spray is the standard silica-dust control for crushing equipment.
Recommended for most sitesScreen media to spec
Priced on your quote
The machine ships with 10 mm and 40 mm decks. Tell us the products you sell and we spec the media to match.
Recommended if you sell spec productService-parts kit
Priced on your quote
Filters, belts and the service items you'll need in year one — on your shelf before you need them.
Wear-parts kit
Priced on your quote
Spare jaw plates and screen wear items, so a change-out doesn't wait on a shipment.
The magnetic separator and the grizzly pre-screen are standard on the 96JC-E. Not sure what your material needs? Say what you're crushing on the quote form and we'll tell you what makes sense — and what doesn't.
Specifications
USA-96JC-E, by the numbers.
U.S. Tier 4 Final configuration. U.S. customary measurements first, with metric equivalents alongside.
Crusher
| Jaw opening | 35.4" × 19.7" (900 × 500 mm) |
| Max feed size | 16.7" (425 mm) |
| Rated production | 60–150 t/h |
| Discharge setting (CSS) | 1⅝" – 4¾" (40–120 mm) |
| Jaw plates | Manganese steel (ZGMn13Cr2) |
Screen
| Type | Two-deck vibrating screen, 2YK1012 |
| Screen size | 39.4" × 47.2" (1,000 × 1,200 mm) |
| Standard media | 10 mm and 40 mm (⅜" and 1⅝") |
| Products | Up to three sized products in one pass |
| Screen conveyor | 31.5" × 11'6" (B800 × 3,500 mm) |
Engine & drive
| Engine | Diesel, 207 HP (154 kW) |
| Emissions | EPA Tier 4 Final |
| Drive | Diesel-hydraulic |
| Controls | Remote control available; configuration confirmed on your quote |
Hopper & feeder
| Hopper capacity | 3.9 yd³ (3 m³) |
| Feeder | Pre-screening vibrating feeder, YK0810 |
| Grizzly opening | 1⅝" (40 mm) |
| Magnetic separator | RCY650 belt-type, standard |
Conveyors
| Main discharge conveyor | 31.5" × 16'5" (B800 × 5,000 mm) |
| Stacking height (main) | 6'7" (2.0 m) |
| Side conveyors | 2 × 15.7" × 10'6" (B400 × 3,200 mm) |
| Stacking height (side) | 5'11" (1.8 m) |
Machine
| Operating weight | 41,888 lb (19,000 kg) |
| Working dimensions (L × W × H) | 41'0" × 15'5" × 8'10" (12,500 × 4,700 × 2,700 mm) |
| Transport dimensions (L × W × H) | 38'1" × 7'3" × 8'4" (11,600 × 2,200 × 2,550 mm) |
| Undercarriage | Steel tracks, 11.8" × 11'6" (300 × 3,500 mm) |
Included with the machine
| Documentation | English operator's and parts manual |
| Warranty | 1-year manufacturer parts warranty |
| Support | 12 months field-service coverage; factory troubleshooting relayed through UPSEN USA |
| Parts | Wear and service parts stocked in the U.S., shipped same or next business day |
Full spec sheet, options and dimensions — sent to your inbox.
Specifications describe the U.S. Tier 4 Final configuration and are subject to change by the manufacturer. Actual production varies with material, feed size, discharge setting, screen media, moisture and operating practice.
Brochure
Get the USA-96JC-E brochure.
Everything on this page in a form you can print, forward to a partner, or hand to your mechanic:
- Full specification sheet, U.S. Tier 4 Final configuration
- Working and transport dimensions
- Screen media, options and what's included with the machine
- How support and the parts warranty work
Enter your email and it's on the way.
Applications
Where the 96JC-E earns its keep.
A 35" × 20" jaw, a 16.7" (425 mm) feed and a two-deck screen cover what a producer needs to make sized product from raw material in one pass. Here's where it fits.
Concrete recycling
Slabs, footings and structure demo into sized base — rebar pulled by the standard magnet.
Asphalt
Broken pavement and millings into RAP, sized off the screen instead of a second machine.
Quarry & pit production
Shot rock, limestone and basalt at production rates, with the screen making spec product.
C&D recycling yards
Mixed inbound loads turned into products you can sell, at 150 tph when the material allows.
Recycled aggregate for sale
Two or three sized products from one pass. Sell what you crush.
Road & site work
Base course made and sized on site, from material that's already there.
Demolition contractors
Process on site instead of paying to haul it away — at the volume a demo job produces.
Material suppliers
One machine that keeps a loader busy and a scale ticket moving.
Replacing a two-machine train
Where a crusher feeds a screener today, one machine, one operator, one setup.
Who you're dealing with
The authorized U.S. distributor, with a direct line to the factory.
You should know exactly who's behind your machine.
UPSEN USA
The authorized U.S. distributor for UPSEN equipment, supporting compact crushing, screening and processing equipment in the U.S. since 2022. Sales, stock, parts and service coordination through one team.
The factory
UPSEN has built mobile crushing, screening and shredding equipment since 2010 — 33 models, ISO 9001 certified, with machines working in more than 80 countries. UPSEN USA has worked directly with the factory's leadership for more than five years. Diesel machines built for the U.S. market carry EPA Tier 4 Final engines.
How we work
- Price published, options priced, delivery quoted to your site
- Wear and service parts stocked in the U.S.
- Field service coordinated by UPSEN USA
- A direct line to the factory when a question needs the people who built the machine
